Franklin  |  SKU: 24-FRA-2145089003GS

Franklin Electric - 4-Inch Encapsulated Motor - 3-Wire Single Phase Model

(FOR STOCK AVAILABILITY, LEAD TIME, OR PRICING, PLEASE CALL +1 (800) 419-5707)

The Franklin Electric stainless Super Encapsulated Motor has been the gold standard for residential and light commercial submersible pumps for decades. Designed for reliable performance in 4-inch or larger water wells, this corrosion-resistant, hermetically sealed motor ensures long-lasting operation in various voltages and applications. Certified to UL 778, CSA C22.2 #108, and NSF/ANSI 61 standards, this motor is a reliable, high-performance solution.

Whether for clean groundwater supply, high-temperature environments, or pollution recovery, it delivers efficient, consistent performance in the most demanding conditions.

Model
$674.01
Shipping calculated at checkout.

Features

  • Built for Durability

    - Corrosion-resistant stainless steel construction
    - Hermetically sealed windings to protect against moisture
    - Handles high downthrust loads for long-term reliability

  • Versatile Applications

    - Available in single-phase (230V) & three-phase (200V-575V) options
    - Self-lubricating design enhances motor lifespan
    - Built-in lightning arrestors protect against power surges

  • Special Features

    - Stainless steel option for acidic, saline, and low-pH water
    - Oil Stripper option for secondary oil recovery or geothermal applications
    - Equipped with chemical-resistant materials for recovery wells

Specifications

2145089003GS
2145581903GS
2243009203GS
2243018802G
2243019204GS
2247022604G
2247038602G
2247038802G
2343058600G
Volts
Volts
230 VAC
220 VAC
230 VAC
230 VAC
230 VAC
230 VAC
230 VAC
230 VAC
200 VAC
Thrust Bearing Rating
Thrust Bearing Rating
650 lb
650 lb
650 lb
1500 lb
650 lb
900 lb
1500 lb
1500 lb
1500 lb
Hz
Hz
60 Hz
50 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
60 Hz
50 Hz
Hp
Hp
1 hp
1 hp
1.5 hp
2 hp
2 hp
3 hp
5 hp
5 hp
2 hp
Type
Type
Water Well
Water Well
Water Well
Sand Fighter
Water Well
Water Well
Water Well
Sand Fighter
Water Well
